V2X On-Board Unit

iW-RainboW-G41V®

Powered by NXP i.MX 8XLite
Hybrid Hub: C-V2X and DSRC Radios
Positioned as an OBU (On-Board Unit) and RSU (Road-Side Unit)
Cellular Connectivity: 4G LTE Cat-4/Cat-M1/NB-IoT
Wireless Connectivity: Wi-Fi 802.11 a/b/g/n/ac and BLE 5.0
4 CAN Ports: CAN FD/HS CAN/LS CAN
High Accuracy GNSS Module & UWB Radio (Ultra Wide Band)
Security: Integrated HSM and TPM
M.2 Expansion Connector: 5G / Wi-Fi 6
IP Enclosure for Rugged Installations

Categories: V2X Solutions, Product Solutions

Downloads

Documents

User Manual

Product User Manual

SPECIFICATION

Processor Core

CPU: NXP i.MX 8XLite
RAM: 1GB LPDDR4 (Upgradable upto 2GB)
FLASH: 8GB eMMC Flash (Upgradable upto 64GB)

V2X Radio and Wireless Transceiver

C-V2X PC5 with 1.28 GHz
DSRC 802.11p operates in the 5.9 GHz band
Ultra-Wideband (UWB) wireless transceiver

Wireless Communication

Cellular:LTE Cat 4/Cat M1/Cat NB1
Wi-Fi: 802.11a/b/g/n/ac with optional support for 802.11ax
Bluetooth: BLE 5.0

Connectors

Enclosure Connector: 36 Pin Micro-fit
External Fakra connector: C-V2X/DSRC
External connector: M.2 with Key B/Key E

Interfaces

CAN: 4 Ports (HS CAN, CAN FD, LS CAN)
10/100 Mbps Ethernet
RS232/RS485

Interfaces

K-Line/LIN Interface
Analog Input x 2
GPIOs x 4 (2DI, 2DO)

Security

Hardware Security Module (HSM)
Trusted Platform Module (TPM)

GNSS

High Accuracy GNSS Module
GPS/GLONASS/BeiDou/Galileo

Software

Operating System: Linux 5.4.70
Protocol Stacks: ISO 15765-4 CAN, ISO 11898, J1939

Sensors

Accelerometer, Gyroscope, Magnetometer
Temperature Sensor

Antenna

1 x GNSS, 1 x Cellular, 1 x WiFi/BLE

Environmental

Operating Temperature: -40°C to +85°C (Excluding Battery)

Enclosure

Protecting Class: IP 67 with tamper detection
Mounting Options: Pole Mounting/Cable Tie

Power Input

- 12V – 36V
- POE support

BUILD INTELLIGENCE ON YOUR CONNECTED MOBILITY WITH V2X CONNECTIVITY HUB

V2V (Vehicle-to-vehicle)

V2I (Vehicle-to-infrastructure)

V2P (Vehicle-to-pedestrian)

Vehicle-to-vehicle communication (V2V) technology allows vehicles to transmit data wirelessly between two vehicles and smart infrastructure. V2X Hub integrated with C-V2X and DSRC communication provides vehicles with 360-degree awareness of the surrounding environment. V2V technology enhances the safety of autonomous vehicles when approached by unmanned or unseen intersection Data from V2V can further be used by intelligent transport system (ITS) to improve traffic management.

V2I technology captures the vehicle generated traffic data such as informing the driver about the safety, movement of vehicles, or other environmental conditions through V2X Connectivity Hub with IP67 enclosure support. It also enables Intelligent Transportation Systems to improve traffic management ranging various applications such as emergency vehicle approaching, hazardous location, pedestrians crossing, wrong way driving, roadwork, stationary vehicle, slow vehicle and environment condition.

Vehicle-to-Pedestrian involves direct communications between vehicles and pedestrians or other vulnerable road users like cyclists within close proximity. V2X Connectivity Hub integrated with C-V2X and DSRC communication is done directly or through the use of network infrastructure. It will facilitate warnings to be provided to the pedestrian of an approaching vehicle, and establishing a broadcast system that alerts drivers on the pedestrians whereabouts and vulnerable road users.
