Artix UltraScale+ FPGA

Artix UltraScale+ FPGA

iW-RainboW-G74M®

  • Artix™ UltraScale™ + FPGA SOM Compatible with AU25P / AU20P / AU15P / AU10P
  • Up to 308K Logic cells & 141K LUTs
  • 12 channels of GTY transceivers up to 16.375Gbps
  • 72 LVDS IOs / 144 SE IOs from HP Bank and 66 SE IOs from HD Bank
  • Two 320pin High Speed B2B Connector
  • Open Harmonized FPGA Module(oHFM) Form Factor: 50mm x 75mm
Categories: ,

Artix UltraScale + FPGA

FPGA
  • Artix US+ SOM with FFVB676 package
  • Up to 308K Logic cells & 141K LUTs
  • GTY Transceivers x 16 @16.375Gbps
  • 72 LVDS IOs / 144 SE IOs from HP Bank and 66 SE IOs from HD Bank
Memory
  • 16-bit 2GB-DDR4 (supports only AU25P/20P)
  • 256MB QSPI Flash
PMIC

Dialog’s DA9062 PMIC with RTC

Clock

Clock Synthesizer

Board to Board Connector1 Interfaces(320pin)

  • EEPROM
  • 4 channels of GTY transceivers up to 16.375Gbps
  • 24LVDS/48SE IOs from HP-BANK 64
  • 24SE IOs from HD-BANK 84
  • 24SE IOs from HD-BANK 86
  • 18SE IOs from HD-BANK 87
  • JTAG
  • SYSMON_DXP/DXN,UART,I2C

Board to Board Connector2 Interfaces(320pin)

  • 12 channels of GTY transceivers up to (16.375Gbps)
  • 24LVDS/48SE IOs Pairs from HP-BANK 65
  • 24LVDS/48SE IOs Pairs from HP-BANK 66

BSP Support

Vivado 24.2

General Features

Power Input

12V through B2B Connector1 & 2

Harmonized FPGA Module(HFM) Form Factor

50mm x 75mm

Operating Temperature

-40°C to +85°C (Industrial Grade)

Environment Specification

REACH & RoHS3 Compliant

Compliance

CE*

Custom Design Sevices

iWave provides end-to-end ODM services, from concept to production, leveraging our in-house expertise in hardware design, software development, FPGA design, and mechanical enclosure design. The FPGA expertise at iWave includes RTL, high speed bus interface and transceivers, storage, video, networking, and high-speed ADC/DAC with the entire product lifecycle, from initial concept to mass production and ongoing support.

iWave's Custom Design Services

Product Design Process

Certification & Qualification

Product Lifecycle Management
