Corazon-AI
Corazon-AI
Corazon-AI is an EdgeAI platform built on a highly adaptive Zynq Ultrascale+ MPSoC device. It features Arm + FPGA architecture and integrates Xilinx Vitis AI Stack built on it. These platforms are coupled with multiple high-speed connectivity options such as Dual GbE, Wi-Fi, BT 5.0, 4G network support via an M.2 expansion slot, Dual CAN, and USB 3.0. With the provision to connect 8 IP cameras, Corazon-AI becomes an ideal fit for EdgeAI Gateways bringing intelligence to the edge.
Applications
-
ADAS
-
Smart Parking
-
ITMS
-
Vehicle Detection
-
Motion Detection
-
Toll Management
-
Face Recognition
-
Car Plate Recognition
-
Queue Management
-
People Counting
Downloads
Corazon-AI
Corazon-AI Gen2
Vitis-AI
- Hardware-accelerated pre-processing and post-processing
- Video Analytics & Real-time decision-making on the Edge
- Deployment ready AI hardware and AI applications
- Heterogeneous ARM + FPGA Architecture
- Custom Solution on the requirement
- Multi-Camera Support – 8 IP up to 1080p, 2 USB3.0, SDI & LiDAR*
- Rapid integration and faster time to market for AI Edge Solutions
- Connectivity Options: Ethernet, Wi-Fi, Bluetooth 5.0, 3G/4G
- Low Latency and power-efficient
- 10+ Year Availability
SPECIFICATIONS
Hardware
CPU & GPU
- Quad-core Arm Cortex-A53 Based APU Up to 1.5GHz
- Dual-core Arm Cortex-R5 RPU up to 600MHz
- ARM MALI – 400MP2 up to 677 MH
Memory
- 32bit, 1GB DDR4 for PL (Upgradable up to 4GB)
- 64bit, 2GB DDR4 with ECC for PS ( up to 4GB)
- Corazon-AI Gen2 : 64bit, 4GB DDR4 with ECC for PS (up to 8GB)
Storage
- 8GB eMMC Flash (Expandable to 256GB)
- EEPROM for MAC Address Secure Key
- M.2 SATA extended storage for recording &USB3.0 x 2
Connectivity & Cameras Supported
- Wi-Fi 802.11 b/g/n/ac, BLE 5.0
- Gigabit Ethernet x 2
- 4G/5G Module & CAN x 2
- Cameras : RTSP(IP) x 8, USB x 2, 3G-SDI x 1, LiDAR
Display & IO’s
- 4K Display Port – Display with Audio
- SPI x 1, CAN x 2, I2C x 1, GPIO header64bit, 2GB DDR4 with ECC for PS ( up to 4GB)
In-built FPGA Module
AI Engine
- DPU 4096 @330MHz for ~1352 GOPs
- DPU 3136 @330MHz for ~1035 GOPs
- Dual Core DPU 4096 @330MHz for ~2704 GOPs1
Encode/Decode
- H.264/H.265
- 16x1080p @ 15fps1
- 8x 1080p @ 30fps
- 4x 1080p @ 60fps
- 32x 480p @ 30fps
- JPEG, MJPEG*
- H.264/H.265
Scalar
- Pre-processing & Post-processing
- 8 x 1080p
1 for Corazon-AI Gen2
General Features
Enclosure Dimension & Form Factor
- Corazon-AI
101mm x 81mm x 33mm (Passive Heat Sink Enclosure )
100mm x 72mm ( Form Factor)
- Corazon-AI Gen2
118.6mm x 97.3mm x 46.8mm ( passive Heat Sink Enclosure)
110mm x 90mm ( Form Factor)
Power Input & Operating Temperature
- 12V, 5A AC Adaptor
- 0°C to +100°C (Extended)
- -40°C to +70°C (Industrial)
Environment Specification & Compliance: REACH, ROHS & CE*
* In Progress
